Performance

An industry leader in ”Environmental Responsibility” with our up to 40 CFM compressor in a compact package. Created from
industry demand, the people at
Airworks have listened well and
responded with a high performance,
fuel efficient, lightweight
compressor for almost any
commercial application imaginable.


Compressor Power

• 32L x 30H x 18W


• 2 Cylinder Liquid Cooled Compact Diesel


• Glow Plugs & Electric Fuel
  Shut Off.


• Fuel Comsumption
  1L / hr at idle = 1.6L/hr at
  100% Load


• Alternate fuel systems available.

• Type: Oil Flooded Rotary Screw


• 18" (W) x 32" (L) x 29" (H)
• Lightweight Aluminum Body / Steel Frame

System Weight

• 354 lbs (160 kgs)

• Liquid to Liquid


• Electric

• Automatic

• 2 Years / 2000 hr on Unit

• Extended Service Plans Available

Safety Features

• 200 psi Pressure Relief Valve


• High Temperature Automatic Shut Down


• Low Oil Pressure Automatic Shut Down


Standard Features

• Diesel Rotaryscrew Compressor up to 40 CFM
• Hour Meter
• Temperature and Oil Pressure Shut Down Protection
• Electric Start
• Charging system maintains truck battery
• Tie into Chassis fuel tank
• No Chassis Idle Time
• No Belts
• No Tow Behinds
• Less Weight
• More Payoad
• Less Fuel

Optional Features

• Direct Mount Hydraulic Pump up to 4500 psi
• Generator/Welder
• Custom Paint and Decals on Body
• Oil Pressure, Temperature and Air Pressure Gauges
• Positve Air Shut Off
• Cold Weather Package - Tying Compressor Cooling System to Chassis Cooling System
• Remote Radio Start / Stop
• Diesel Tank Attached
• Battery Skid and 12V Battery Pak
• Skid mounted units (self contained)
• Portable Units Available
